Mini DVR 5.8G-FPV Video Recorder Module CVBS Signal Input Support 32GB

Black Mini DVR 5.8G-FPV Video Recorder Module CVBS Signal Input with Metal Shell Support 32GB TF Card

Features:

- Small size and light weight.

- Low power consumption, operating current 200mA.

- Aluminum alloy casing (CNC processing).

- Support 32GB TF card (10 level recommended).

- Built-in 3.7V/400mAh lithium-ion polymer battery.

- Universal USB charging interface.

- High-precision 4-level battery power indicator.

- Multi-language menu, 11 menu language choices.

- CVBS signal input (built-in video decoder).

- Support playback and AV signal output (built-in video encoder).

Specification:

- System startup time: 3 seconds

- Video input format: NTSC/PAL

- Video input impedance: 75ohms Typ.

- Video compression format: MJPEG

- Record file resolution: VGA (640 x 480) / D1 (720 x 480) / HD (1280 x 720) selectable

- Record file format: AVI

- Recording sound: ON/OFF selectable

- Cycle recording time: 10min/20min/30min optional

- Frame rate: 30 Frames

- Video output format: NTSC/PAL switchable

- Video output impedance: 75ohms Typ.

- Memory card: TF card, support up to 32GB (C10 recommended)

- Menu language: 11 language choices

- Optical frequency: 50Hz/60Hz can be selected

- Video playback: CVBS output (connected to the monitor)

- Audio input interface: 3.5mm AV jack

- Audio output interface: 3.5mm AV jack

- Charging interface: micro USB interface

- Charging voltage: 5V DC

- Charging current: 500mA Max

- Battery (non-removable): built-in 3.7V/400mAh lithium ion polymer battery

- Battery life: each working load is 1.5 to 2 hours of working time.

- Operating temperature: -10 ~ 60°C

- Operating humidity: 85% RH

- Dimension: 53mm x 33mm x 9mm

- Weight: 24.5g

- Menu language: English, French, German, Italian, Spanish, Portuguese, Traditional Chinese, Simplified Chinese, Japanese, Russian, Korean.

Package Included:

- 1 x FPV Mini DVR

- 2 x AV Cable

- 1 x Magic Strap
